Planet VC-201A User Manual

32
6. FAQ
Q1: What voltage that VC-201A / VC-202A / VC-204 used?
A1: 5V DC, 2A
Q2: What is VDSL2?
A2: VDSL2 (Very High-Bit-Rate Digital Subscriber Line 2),
G.993.2 is the newest and most advanced standard of
xDSL broadband wire line communications.
Designed to support the wide deployment of Triple Play
services such as voice, data, high denition television
(HDTV) and interactive gaming, VDSL2 enable opera-
tors and carrier to gradually, exibly, and cost efciently
upgrade exiting xDSL-infrastructure.
Q3: What is the best distance for VC-201A / VC-202A / VC-
204?
A3: In order to guarantee the stability and better quality of
network, so we would suggest the distance within 1.6 kilo-
meter is the best for VC-201A / VC-204 and 3.0kilometer
for VC-202A.
Q4: What is the best date rate for VC-201A / VC-202A / VC-
204?
A4: We provide the data rate of the VC-201A / VC-204 is up
to 100Mbps/55Mbps and the VC-202A is up to 100Mbps/
65Mbps (downstream / upstream) in 200 meters
Q5: Can VC-201 compatible with VC-201A / VC-204?
A5: Currently NO. Although VC-201 (prole 12a) and VC-201A
/ VC-204 (prole 17a) are base on ITU-T G.993.2 VDSL2,
but with different Proles, so far they are not compatible
with each other.

Planet VC-201A Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1600 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	69 mm
Width	97 mm
Height	26 mm
Weight	400 g
