Planet VC-201A User Manual

14
2. Hardware Description
VC-201A / VC-204
The VC-201A / VC-204 provides 2 RJ-11 ports for voice
connection (like telephone) and for network line connection.
VC-202A
The VC-202A provides 1 BNC connector and supports 50 or 75
ohm cable with distance up to 3.0km.
The VC-201A / VC-202A provide 1 RJ-45 port and VC-204
provides 4 RJ-45 ports with two different running speed –
10Mbps and 100Mbps. It will distingish the speed of incoming
connection automatically.
This section describes the hardware features of the Ethernet
over VDSL2 Converter. For easier control of the converter,
familiarize yourself with its display indicators and ports. Front
panel illustrations in this chapter display the unit LED indicators.
Before connecting any network device to the converter, read this
chapter carefully.
n
n

Planet VC-201A Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1600 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	69 mm
Width	97 mm
Height	26 mm
Weight	400 g
