Planet VC-201A User Manual

13
Storage
Temperature
-10~70ºC
Operating
Humidity
10% to 90%, relative humidity, non-condensing
Storage
Humidity
10% to 90%, relative humidity, non-condensing
Standard Conformance
Regulation
Compliance
FCC Part 15 Class A, CE
Standards
Compliance
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3x Full Duplex Pause frame Flow Control
ITU-T
• G.993.1 (VDSL)
• G.997.1
• G.993.2 VDSL2 (Prole 17a)
* The actual data rate will vary on the quality of the copper wire
and environment factors.

Planet VC-201A Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1600 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	69 mm
Width	97 mm
Height	26 mm
Weight	400 g
