31
5. Troubleshooting
SYMPTOM:
VDSL LNK LED does not light after wire is connected to the
VDSL port.
CHECKPOINT:
1. Verify the length of the wire connected between two VC-201A
/ VC-204 is not more than 2.0km and VC-202A is not more
than 3.0km. Please also try to adjust the DIP switch of VC-
201A / VC-202A / VC-204 to other SNR mode.
2. Please note you must use one VC-201A / VC-202A / VC-204
with CO mode and the other VC-201A / VC-202A / VC-204
with CPE mode, connect to each other to make it work.
SYMPTOM:
TP LED does not light after cable is connected to the port.
CHECKPOINT:
1. Verify you are using the Cat.5, 5e or 6 cables with RJ-45
connector to connect to the port.
2. If your device (like LAN card) supports to Auto-Negotiation,
please try to modify at a xed speed of your device by manu-
ally.
3. Check the converter and the connected device’s power are ON
or OFF.
4. Check the ports cable is rmly seated in its connectors in the
switch and in the associated device.
5. Check the connecting cable is good.
6. Check the power adapters are functional, including the
connecting device.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Planet VC-201A and is the answer not in the manual?

Planet VC-201A Specifications

General IconGeneral
Duplex systemFull, Half
Auto MDI/MDI-XYes
Ethernet LAN data rates10, 100 Mbit/s
Ethernet interface typeFast Ethernet
Converter input interface100Base-TX
Maximum data transfer rate100 Mbit/s
Fiber optic connector-
Connectivity technologyWired
Ethernet LAN (RJ-45) ports1
Wavelength- nm
Maximum transfer distance1600 m
InternalNo
CertificationFCC Part 15 Class A, CE
Product colorBlack
Storage temperature (T-T)-25 - 70 °C
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth69 mm
Width97 mm
Height26 mm
Weight400 g
