Planet VC-201A User Manual

30
4. Power Information
The power jack of VC-201A / VC-202A / VC-204 is with 2.5mm
in the central post and required +5VDC power input. It will
conform to the bundled AC-DC adapter and Planet’s Media
Chassis. If you have encountered the issue to make the power
connection, please contact your local sales representative.
Please keep the AC-DC adapter as spare parts when your VC-
201A / VC-202A are installed to a Media Chassis.
2.5mm
DC Receptacle 2.5mm
+5V for each slot
For Media Chassis DC receptacle is 2.5mm wide that conforms
to and matches the VDSL2 Converter 2.5mm DC jack's central
post. Do not install any improper devices in Media Chassis

Planet VC-201A Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1600 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	69 mm
Width	97 mm
Height	26 mm
Weight	400 g
