1. Introduction
1.1 Checklist
Check the contents of your package for following parts:
VC-201A / VC-202A / VC-204 x 1
5V DC / 2A AC-to-DC Power Adapter x 1
RJ-11 Telephone Line x 1 (VC-201A / VC-204 only)
User’s Manual x 1
If any of these items are missing or damaged, please contact
your dealer immediately, if possible, retain the carton including
the original packing material, and use them against to repack
the product in case there is a need to return it to us for repair.
1.2 Ethernet over VDSL2 Bridge Description
PLANET’s state-of-the-art Ethernet-over-VDSL2 products are
based on two core networking technologies: Ethernet and
VDSL2 (Very-high-data-rate Digital Subscriber Line
2). This technology offers the absolute fastest possible data
transmission speeds over existing copper telephone lines or
coaxial cables without the need for rewiring.
The VC-201A / VC-202A / VC-204 Ethernet Over VDSL2
Converter has a switching architecture with RJ-45 10/100Mbps
Ethernet port and one asymmetric or symmetric Ethernet over
VDSL port (Asymmetric means upstream and downstream
rate are not the same and Symmetric means upstream and
downstream rate are similar) – the VDSL port can be RJ-11
connector (VC-201A / VC-204) or BNC Connector (VC-202A).
The VC-201A / VC-202A / VC-204 can be set to Central Ofce
(CO) or Customer Premises Equipment (CPE) mode via a DIP
switch. When VC-20X-CO (VC-201A / VC-204) is connected with
other VC-20X-CPE (VC-201A / VC-204) device, the performance
