Planet VC-201A User Manual

11
1.4 Specications
Product VC-201A VC-204 VC-202A
Hardware Specication
Ports
10/100
Base-TX
1 x RJ-45,
Auto-negotiation
Auto-MDI/MDI-X
4 x RJ-45,
Auto-negotiation
Auto-MDI/MDI-X
1 x RJ-45,
Auto-negotiation
Auto-MDI/MDI-X
VDSL 1 x RJ-11, female Phone Jack
1 x BNC,
female connector
PHONE
1 x RJ-11, Built-in splitters for
POTS connection
-
DIP Switch 4 position DIP switch
Functionality
•
CO / CPE mode select
• Selectable
fast and interleaved mode
• Selectable target
Band Plan
• Selectable target
SNR mode
Encoding
• VDSL-DMT
- ITU-T G.993.1 VDSL
- ITU-T G.997.1
- ITU-T G.993.2 VDSL2 (Prole 17a Support)
LED Indicators
One Power One Power One Power
3 for RJ-11/
VDSL2
4 for RJ-11/
VDSL2
3 for RJ-11/VDSL2
2 for RJ-45
10/100Base-TX
port
1 for RJ-45
10/100Base-TX
port
2 for RJ-45
10/100Base-TX port
Cabling
Ethernet
• 10Base-T: 2-pair UTP Cat.3, 4, 5 up to 100m (328ft)
• 100Base-TX: 2-pair UTP Cat.5, 5e, 6 up to 100m (328ft)
VDSL
Twisted-pair telephone wires
(AWG24 or better) up to 1.6km
50 ohm, RG58A/U,
RG58C/U, RG58/U
or 75 ohm, RG6
(Distance 3.0km)

Planet VC-201A Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1600 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	69 mm
Width	97 mm
Height	26 mm
Weight	400 g
