Planet VC-201A User Manual

21
Target SNR (Signal Noise Ratio) Margin
• When xed SNR margin is selected, the system will main-
tain the SNR margin at 9 dB across all usable loop length.
Note
By default setting, the four DIP switch at “ON”
position and operate as “CPE”. For operate as
“CO”, please adjust the DIP 1 switch to “OFF”
position. Adjust other DIP switch setting to fill
different network application demand.
Please power off the Ethernet over VDSL2 Converter before
making any transmission mode adjustment.
2.2.2 DC Power Jack
VC-201A / VC-202A / VC-204 require 5V DC power input. It
will conform to the bundled AC adapter. If you have the issue
to make the power connection, please contact your local sales
representative.
Note
1. The device is a power-required device, it
means, it will not work till it is powered. If
your networks should active all the time, please
consider using UPS (Uninterrupted Power
Supply) for your device. It will prevent you
from network data loss or network downtime.
2. In some area, installing a surge suppression
device may also help to protect your Ethernet
Over VDSL2 Converter from being damaged by
unregulated surge or current to the Ethernet
over VDSL2 Converter or the power adapter.
n

Planet VC-201A Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1600 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	69 mm
Width	97 mm
Height	26 mm
Weight	400 g
