Planet VC-201A User Manual

20
DIP-1 DIP-2 DIP-3 DIP-4
Mode Channel Band Plan SNR
OFF CO Interleave Symm 9dB
ON (default) CPE Fast Asymm 6dB
CO / CPE
• CO (Central Ofce) – the Master device mode, usually
the CO device will be located at the data center of ISP or
enterprise to link to the backbone.
• CPE (Customer Premises Equipment) – the Slave device
mode, usually the CPE device will be located at branch
ofce, home or remote side as the long reach data
receiver. The CPE can be connected to the PC, IP Camera
or Wireless Access Point and etc network devices.
Note
When the Ethernet Over VDSL2 Converter operate
at CPE mode, the DIP switch 2,3,4 is no function.
Fast and Interleave mode
• Fast mode guarantees a minimum end to end latency less
than 1 ms.
• Interleaved mode provides impulse noises protection with
a duration less than 250 us. Interleaved mode has a
maximum end to end latency of 10m sec.
Band Plan
• User can switch the Band Plan either Symmetric or Asym-
metric by their own. When Symmetric is selected that
provides better upstream performance, when Asymmetric
is selected that provides better downstream performance.
Refer to table above for details.
n
n
n

Planet VC-201A Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1600 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	69 mm
Width	97 mm
Height	26 mm
Weight	400 g
