Planet VC-201A User Manual

18
VDSL
LED Color Function
ACT Green
Light
Indicate that the VDSL link is
established.
Fast
Blink
Indicate that the VDSL link is at
training status (about 10 seconds).
Slow
Blink
Indicate that the VDSL link is at idle
status.
Sync Green
Light
Indicate that the VDSL link is
established.
Fast
Blink
Indicate that the VDSL link is at
training status (about 10 seconds).
Slow
Blink
Indicate that the VDSL link is at idle
status.
CO Green Light
Indicate the VDSL Bridge is running
at CO mode.
CPE Green Light
Indicate the VDSL Bridge is running
at CPE mode.
10/100Base-TX Port
LED Color Function
LNK/ACT Green
Light Indicate that the port is link up.
Blink
Indicate that the Converter is
actively sending or receiving data
over that port.
Off Indicate that the port is link down.
n
n

Planet VC-201A Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1600 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	69 mm
Width	97 mm
Height	26 mm
Weight	400 g
