Planet vc-231 User Manual

18
n DIP-1: Mode (CO/CPE)
CO (Central Ofce) – the Master device mode, usually
the CO device will be located at the data center of ISP or
enterprise to link to the backbone.
CPE (Customer Premises Equipment) – the Slave device
mode, usually the CPE device will be located at branch
ofce, home or remote side as the long reach data receiver.
The CPE can be connecting to the PC, IP Camera or Wire-
less Access Point or other network devices.
Note
When the Ethernet Over VDSL2 Converter oper-
ates at CPE mode, the DIP switch 2, 3, 4 is no
function.
n DIP-2: Channel (Fast and Interleave mode)
Fast mode guarantees a minimum end-to-end latency less
than 1 ms.
Interleaved mode provides impulse noises protection for
any impulse noise with a duration less than 250 us. Inter-
leaved mode has a maximum end to end latency of 10m
sec.
n DIP-3: Prole (17a/30a)
User has the ability to select prole. When 30a is selected
that provides better downstream/upstream performance in
short distance, when 17a is selected that provides longer
distance link capability. Refer to section 1.4 specication for
details.
n DIP-4: SNR (9dB/6dB) Target SNR (Signal Noise Ratio)
Margin
When SNR margin is selected, the system provide 9dB/6dB
SNR margin for across all usable loop length.
l
l
l
l
l
l

Planet vc-231 Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1400 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Input current	2 A
Input voltage	5 V
Power consumption (typical)	6.6 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	97 mm
Height	26 mm
Weight	199 g
