User Manual of WDAP-C3000AX, WDAP-3000AX, WDAP-W3000AX
- 49 -
Step 4: Network Interface Wireless Connection
Set up the Security Settings as shown in Figure 5-9.
Figure 4-12: Wireless Connection- set up
Select the Mesh role for Master or Node to enable Mesh function.
The default configuration is disabled.
Select 2.4GHz or 5GHz for MESH ID radio.
Enter the Mesh ID, just like SSID, or use the button to
discover Mesh ID from the Master/Node Mesh AP.
Selector is for the encryption for the sake of security.
Enter the password for Mesh ID; the default configuration is null.
Press this button for the next step.
Press this button for the previous step.
Press this button to undo any changes made locally and revert to
previously saved values.
