1.4. Product Specification
Product
WNRT-300
150Mbps 802.11n Wireless AP / Router
Hardware Specification
Interface LAN/WAN 1 x 10/100Mbps Auto MDI/MDI-X RJ45 port
Gain: 1 x Internal 2dBi Antenna
Antenna
Orientation: Omni-directional
Button/Switch
Front panel (from left to right):
Mode Selection Switch (Router/Client/AP)
WPS Button
Power On/Off Switch
Rear panel:
Reset button
*Push for above 5 seconds to reset to factory default settings
LED Indicators PWR, WLAN, WAN/LAN, WPS, CHG
Material Plastic
Dimension (W x D x H) 88 x 62 x 18 mm
Weight
With battery: 80g
Without battery: 58g
Battery Built-in Rechargeable Li-ion Battery (3.7V, 1050mAh)
Power Requirement DC 5V , 0.4A maximum, connected through mini-USB connector
Power Adapter
AC Input: 100~240V AC (50/60Hz)
DC Output: 5V with max. 1A current
Standard Accessory
Power Adapter x 1, USB Cable x 1, Ethernet Cable x 1, Li-ion Battery x 1, CD-ROM x 1,
Quick Guide x 1
Wireless Interface Specification
Standard Compliance with IEEE 802.11b/g/n
Frequency Band 2.4~2.4835GHz
Extend Frequency DSSS
Modulation Type DBPSK, DQPSK, QPSK, CCK and OFDM (BPSK/QPSK/16-QAM/ 64-QAM)
Data Transmission
Rates
11n: Up to 150Mbps (Dynamic)
11g: Up to 54Mbps (Dynamic)
11b: Up to 11Mbps (Dynamic)
Transmission Distance
Indoor up to 100m
outdoor up to 300m (it is limited to the environment)
Channel
America/ FCC: 2.412~2.462GHz (11 Channels)
Europe/ ETSI: 2.412~2.472GHz (13 Channels)
Japan/ TELEC: 2.412~2.484GHz (14 Channels)
Max. RF Power 20 dBm (EIRP)
Receive Sensitivity
135M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
Software Features
Operation Mode
AP
Router
Client
(Switchable by H/W)
