Planet XT-705A User Manual

15
3. Installation
This section describes the functionalities of the Media
Converter’s components and guides you to how to install it on
the desktop. Basic knowledge of networking is assumed. Please
read this chapter completely before continuing.
3.1 Stand-alone Installation
Step 1: Unpack the Media Converter.
Step 2: Connect the 5V DC power adapter to the XT-705A and
verify that the Power LED lights up.
(Please refer to the 2.4 Power Information section
for power input.)
Step 3:
3-1: Prepare a twisted-pair, straight-through Category
5e/6/7 UTP cable for Ethernet connection.
3-2: Prepare a ber cable for connection to the 10GBASE-T
SFP+ slot, and make sure both sides of the SFP
transceiver are with the same media type.
(Please refer to the 3.5 Cable Connection section for
the type of connection.)
Step 4:
4-1: Insert one side of Category 5e/6/7 cable into the
Media Converter Ethernet port (RJ45) while the other
side of Category 5e/6/7 cable into the network devices’
Ethernet port (RJ45), e.g., switch, PC or server.
The UTP port (RJ45) LED on the Media Converter will
light up when the cable is connected with the network
device. (Please refer to the 2.2 LED Indicators
section for the functions of LED lights.)

Planet XT-705A Specifications

General

Jumbo frames	16000
Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat5, Cat5e, Cat6, Cat6a, Cat7
Ethernet interface type	2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Maximum data transfer rate	10000 Mbit/s
Fiber ethernet cabling technology	10GBASE-X
Fiber optic connector	SFP+
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Internal	No
Certification	FCC Part 15 Class A, CE
LED indicators	Link, Power
Housing material	Metal
Input current	2 A
Input voltage	5 V
Power consumption (typical)	26 W
Wavelength	- nm
Fiber mode structure	Multi-mode, Single-mode
Maximum transfer distance	60000 m
Fiber cable diameters supported (core/cladding)	9/125, 50/125, 62.5/125 µm
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	94 mm
Height	26 mm
Weight	180 g
