Planet XT-705A User Manual

8
 Automatic address learning and address aging
Case and Installation
 External 5V DC, 2.5A power supply
 DIN-rail and wall-mount design
 Supports 6000 VDC Ethernet ESD protection
 100 meters over Cat 6A / Cat7 at 10Gbps
 0 to 50 degrees C operating temperature
 Co-works with PLANET’s 10”/19” Media Converter Chassis
(MC-700/MC-1500/MC-1500R/MC-1500R48)
 Plug and Play installation
1.4 ProductSpecications
Model XT-705A
Hardware Specications
Copper
Interface
1 x 10G/5G/2.5G/1G/100BASE-T RJ45
Auto-MDI/MDI-X, auto-negotiation
Fiber Optic
Interface
1 x 10GBASE-X R SFP+ interface.
LED
System:
PWR (Green)
10G/5G/2.5G/1G/100 BASE-T RJ45
Interfaces:
1G/10G LNK (Orange)
5G/2.5G/100M LNK (Green)
Switch
Processing
Scheme
Store and Forward

Planet XT-705A Specifications

General

Jumbo frames	16000
Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat5, Cat5e, Cat6, Cat6a, Cat7
Ethernet interface type	2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Maximum data transfer rate	10000 Mbit/s
Fiber ethernet cabling technology	10GBASE-X
Fiber optic connector	SFP+
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Internal	No
Certification	FCC Part 15 Class A, CE
LED indicators	Link, Power
Housing material	Metal
Input current	2 A
Input voltage	5 V
Power consumption (typical)	26 W
Wavelength	- nm
Fiber mode structure	Multi-mode, Single-mode
Maximum transfer distance	60000 m
Fiber cable diameters supported (core/cladding)	9/125, 50/125, 62.5/125 µm
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	94 mm
Height	26 mm
Weight	180 g
