4. Troubleshooting
This chapter contains information to help you solve issues. If
the Media Converter is not functioning properly, make sure
the Media Converter is set up according to instructions in this
manual.
The per port LED is not lit
Solution:
Check the cable connection of the Media Converter.
Performance is bad
Solution:
Check the speed duplex mode of the partner device. The Media
Converter usually runs in auto-negotiation mode. If the partner
is set to half duplex, the performance will be poor.
Per port LED is lit, but the trafc is irregular
Solution:
Check that the attached device is not set to dedicate full duplex.
Some devices use a physical or software switch to change
duplex modes. Auto-negotiation may not recognize this type of
full-duplex setting.
Why the Media Converter doesn’t connect to the network
Solution:
Check per port LED on the Media Converter. Make sure the
cable is installed properly. Make sure the cable is the right type.
Turn off the power. After a while, turn on the power again.

Planet XT-705A Specifications

General

Jumbo frames	16000
Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat5, Cat5e, Cat6, Cat6a, Cat7
Ethernet interface type	2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Maximum data transfer rate	10000 Mbit/s
Fiber ethernet cabling technology	10GBASE-X
Fiber optic connector	SFP+
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Internal	No
Certification	FCC Part 15 Class A, CE
LED indicators	Link, Power
Housing material	Metal
Input current	2 A
Input voltage	5 V
Power consumption (typical)	26 W
Wavelength	- nm
Fiber mode structure	Multi-mode, Single-mode
Maximum transfer distance	60000 m
Fiber cable diameters supported (core/cladding)	9/125, 50/125, 62.5/125 µm
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	94 mm
Height	26 mm
Weight	180 g
