Appendix A: Approved PLANET SFP+
Transceivers
PLANET Media Converter supports 100/1000 dual mode with
both single mode and multi-mode SFP+ transceivers. The
following list of approved PLANET SFP+ transceivers is correct at
the time of publication:
Available 10Gbps Modules
MTB-RJ 10GBASE-T SFP+ Copper Fiber Optic Module - 30m
MTB-SR 10GBASE-SR mini-GBIC module - 300m
MTB-LR 10GBASE-LR mini-GBIC module – 10km
MTB-TSR
10GBASE-SR mini-GBIC module - 300m (-40~75
degrees C)
MTB-TLR
10GBASE-LR mini-GBIC module – 10km (-40~75
degrees C)
MTB-LA20
10GBASE-LX (WDM,TX:1270nm) mini-GBIC module
- 20km
MTB-LB20
10GBASE-LX (WDM,TX:1330nm) mini-GBIC module
- 20km
MTB-LA40
10GBASE-LX (WDM,TX:1270nm) mini-GBIC module
- 40km
MTB-LB40
10GBASE-LX (WDM,TX:1330nm) mini-GBIC module
- 40km
MTB-LA60
10GBASE-LX (WDM,TX:1270nm) mini-GBIC module
- 60km
MTB-LB60
10GBASE-LX (WDM,TX:1330nm) mini-GBIC module
- 60km

Planet XT-705A Specifications

General

Jumbo frames	16000
Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat5, Cat5e, Cat6, Cat6a, Cat7
Ethernet interface type	2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Maximum data transfer rate	10000 Mbit/s
Fiber ethernet cabling technology	10GBASE-X
Fiber optic connector	SFP+
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Internal	No
Certification	FCC Part 15 Class A, CE
LED indicators	Link, Power
Housing material	Metal
Input current	2 A
Input voltage	5 V
Power consumption (typical)	26 W
Wavelength	- nm
Fiber mode structure	Multi-mode, Single-mode
Maximum transfer distance	60000 m
Fiber cable diameters supported (core/cladding)	9/125, 50/125, 62.5/125 µm
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	94 mm
Height	26 mm
Weight	180 g
