Planet XT-705A User Manual

6
1.2 Product Overview
Flexible and Reliable Network Distance Extension Solution
PLANET XT-705A Media Converter is equipped with one
10G/5G/2.5G/1G/100BASE-T auto-negotiation port and
one 10GBASE-X SFP+ slot. It supports 10Gigabit Ethernet
media conversion from copper 10GBASE-T to ber multi-mode
or single-mode, utilizing 10GBASE-SR or 10GBASE-LR SFP+
transceiver installed in the SFP+ slot to extend distances to
servers, switches and patch panels. The deployment distance
can be extended from 300 meters (multi-mode) to up to 60
kilometers (single-mode).They are designed for use in network
environments where the ultra-high bandwidth provided by
10Gigabit Ethernet is required, for example, data center cloud
computing, enterprise backbones, campus networks, and carrier
infrastructure.
High Performance 10Gbps Ethernet Capacity
The XT-705A offers wire-speed packets transfer performance
without risk of packet loss. The high data throughput of the
device makes it ideal for most Gigabit environments. With a
20Gbps internal fabric and featuring auto negotiation support
in its 10 Gigabit port, the XT-705A Media Converter can
handle large amounts of data in a secure topology linking to a
backbone or high capacity servers.
Fiber-optic Linking Capability Enables Extension of
Network Deployment
The SFP+ slot of the XT-705AT is compatible with 10GBASE-SR
or 10GBASE-LR (Small Form Factor Pluggable) ber-optic
transceivers. The ber optic uplink capability guarantees the
throughput to all nodes hooked into the network and the 10
Gigabit Ethernet distance can be extended from 300 meters
(multi-mode ber cable) to 10/40/60 kilometers (single-mode

Planet XT-705A Specifications

General

Jumbo frames	16000
Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat5, Cat5e, Cat6, Cat6a, Cat7
Ethernet interface type	2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Maximum data transfer rate	10000 Mbit/s
Fiber ethernet cabling technology	10GBASE-X
Fiber optic connector	SFP+
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Internal	No
Certification	FCC Part 15 Class A, CE
LED indicators	Link, Power
Housing material	Metal
Input current	2 A
Input voltage	5 V
Power consumption (typical)	26 W
Wavelength	- nm
Fiber mode structure	Multi-mode, Single-mode
Maximum transfer distance	60000 m
Fiber cable diameters supported (core/cladding)	9/125, 50/125, 62.5/125 µm
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	94 mm
Height	26 mm
Weight	180 g
