Planet XT-705A User Manual

7
ber cable). It is ideal for applications within the data centers
and distributions.
Easy Chassis Installation
The XT-705A Media Converter can be used as a stand-alone
unit or as a slide-in module to the PLANET Media Converter
Chassis (MC-700 and MC-1500 chassis series). The media
chassis can assist in providing DC power to the XT-705A Media
Converter to maintain the ber-optic network at one centralized
location. It can be DIN-rail or wall mounted for efcient use of
cabinet space.
Low Power Consumption
The XT-705A adopting the advanced chip technology has the
power-saving feature like a low power consumption of only 3.75
watts when in full operation.
1.3 Product Features
XT-705A Physical Port
 One 10G/5G/2.5G/1G/100BASE-T RJ45 interface with auto
MDI/MDI-X function
 One 10GBASE-X SFP+ slot
Layer 2 Features
 IEEE 802.3u/802.3ab/802.3bz/802.3ae Ethernet standard
compliant
 Supports auto-negotiation and 100Mbps half/full duplex and
1/2.5/5/10Gbps full duplex mode
 Prevents packet loss with back pressure (half-duplex) and
IEEE 802.3x pause frame ow control (full-duplex)
 16K jumbo frame size support

Planet XT-705A Specifications

General

Jumbo frames	16000
Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat5, Cat5e, Cat6, Cat6a, Cat7
Ethernet interface type	2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Maximum data transfer rate	10000 Mbit/s
Fiber ethernet cabling technology	10GBASE-X
Fiber optic connector	SFP+
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Internal	No
Certification	FCC Part 15 Class A, CE
LED indicators	Link, Power
Housing material	Metal
Input current	2 A
Input voltage	5 V
Power consumption (typical)	26 W
Wavelength	- nm
Fiber mode structure	Multi-mode, Single-mode
Maximum transfer distance	60000 m
Fiber cable diameters supported (core/cladding)	9/125, 50/125, 62.5/125 µm
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	94 mm
Height	26 mm
Weight	180 g
