Planet XT-705A User Manual

9
ESD
Protection
6KV DC
Enclosure Compact-sized metal case
Installation
Desktop, wall mountable
Media convert Chassis installation
Optional DIN-rail kit
Dimensions
(WxDxH)
94 x 70 x 26mm
Weight 180g (device only)
Power
Requirements
5V DC, 2A max.
Power
Consumption
3.75 watts / 12.8 BTU per hour max.
Converter Specications
Flow Control
Back pressure for half duplex
IEEE 802.3x pause frame for full duplex
Fabric 20Gbps
Throughput
(packet per
second)
2.48Mpps@64bytes
Address Table
9K entries, automatic source address learning
and aging
Jumbo Frame 16K

Planet XT-705A Specifications

General

Jumbo frames	16000
Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat5, Cat5e, Cat6, Cat6a, Cat7
Ethernet interface type	2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Maximum data transfer rate	10000 Mbit/s
Fiber ethernet cabling technology	10GBASE-X
Fiber optic connector	SFP+
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Internal	No
Certification	FCC Part 15 Class A, CE
LED indicators	Link, Power
Housing material	Metal
Input current	2 A
Input voltage	5 V
Power consumption (typical)	26 W
Wavelength	- nm
Fiber mode structure	Multi-mode, Single-mode
Maximum transfer distance	60000 m
Fiber cable diameters supported (core/cladding)	9/125, 50/125, 62.5/125 µm
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	94 mm
Height	26 mm
Weight	180 g
