SINUS EXPOSURE PROGRAM
42 Planmeca Proline XC Panoramic X-ray
User's manual
Touch the Entry field to move the rotating assembly to
the ready position and the cassette carriage to the
loading position if they are not already in that position.
Touch the temple support key to open the temple
supports if they are not already open.
Guide the patient towards the unit so that they are
facing the chin support.
Touch either of the height adjusting arrows to adjust
the height of the vertical carriage until the opening in
the chin support is approximately level with the
patient’s mouth.
Ask the patient to step forward, grasp the patient
handles and press their lips against the chin support.
The patient’s nose must rest on top of the support and
their mouth must be closed.
Press the temple support key to close the temple
supports.
Touch either of the Layer arrows to switch the three
patient positioning lights on so that the patient can be
positioned.
Stand behind the patient and check that the patient’s
shoulders are level and the neck muscles relaxed.
Position the patient’s head so that the midsagittal
plane coincides with the midsagittal light beam. Make
sure that the patient is looking straight ahead as the
Cassette carriage
in loading position
Closed
Open Open
Midsagittal plane
light
