Planmeca Proline XC Panoramic X-ray 41
SINUS EXPOSURE PROGRAM
User's manual
11 SINUS EXPOSURE PROGRAM
All exposure values given in this section are based on
Kodak Ektavision film and Kodak Ektavision screen. If
you are using a different film and screen combination
you may have to adjust these values.
This procedure will produce an exposure of the
maxillary sinus along the plane selected. If the child
mode is selected the width of the exposed area will be
slightly reduced.
Use the chin support for this exposure.
Select the sinus exposure program on the Select
program type display, see section “7.3 Selecting sinus
exposure program” on page 20.
Select the child mode on the main display if the patient
is a child or a very small adult.
Select the correct exposure values for the patient
being X-rayed according to the values in the following
table. Note that the kV value for a sinus exposure is
4kV higher than the corresponding panoramic
exposure.
SINUS EXPOSURE VALUES
Based on Kodak Ektavision film and Kodak Ektavision screen
PATIENT kV VALUE mA VALUE
Child up to 6 years
a
a. Use the CHILD MODE.
64 4
Child 7 - 12 years 66 5
Adult female or small male 68 6
Adult male 72 8
Large adult male 76 10
Sinus exposure
Chin support
