Planmeca Proline XC - Page 61

Planmeca Proline XC Panoramic X-ray 57
USER’S STATEMENT FOR PLANMECA PROLINE XC PANORAMIC X-RAY
User's manual
Target angle with respect to the reference axis
5°
Filtration in terms of quality equivalent filtration of the X-ray tube
Inherent filtration at least 0.8 Al/50 kV according to IEC 522/1976
Emission & filament characteristics of the X-ray tube
Maximum X-ray tube assembly heat content
400 kJ
FILAMENT CURRENT (A)
FILAMENT VOLTAGE (V)
TUBE CURRENT (mA)
