ProMax X-ray unit with Dimax3 13
PROGRAMS
User’s Manual
Bitewing panoramic program
This program produces bitewing-like images from
premolar and molar areas including parts of maxilla,
mandible and rami.
The bottom of the maxillary sinus and as well as the
mandibular canal and the mental foramen are also visible.
The bitewing program uses improved interproximal
angulation projection geometry.
Using the bitewing program reduces the radiation dose by
50% compared to the normal panoramic program.
Image sizes of the panoramic programs
Program Real size (W x H)
mm
Size on receptor
(W x H) mm
Magnification Layer
thickness (mm)
Panoramic adult 225 x 108 270 x 130 1.2x 10 - 48
child 192 x 92 230 x 110
Bitewing
panoramic
adult 67 x 145 100 x 218 1.5x 10 - 26
child 56 x 120 84 x 180
layer laser beam
