SINUS EXPOSURE
86 ProMax X-ray unit with Dimax3
User’s Manual
12 SINUS EXPOSURE
This procedure will produce an exposure of the maxillary
sinus along the plane selected.
Use the chin support for this exposure. Insert the chin
support into the adapter. Insert the adapter into the holes
in the patient support table.
Select the sinus program you require, refer to section 8.4
“Selecting sinus exposure program” on page 44.
Select the correct exposure parameters for the patient
being X-rayed according to the values in the following
tables. Note that the values depend on the selected sinus
program.
NOTE If the required diagnostic value can be reached
with lower mA values than the following table
indicates, you can use those lower values.
Always try to minimize the radiation dose to the
patient.
NOTE Increase the kV value in the enhanced resolution
mode by 2 kV and the mA value by 2 mA.
EXPOSURE VALUES
for sinus program “Sinus PA rot”
PATIENT kV VALUE mA VALUE
Child up to 6 years of age 72 6
Child 7-12 years of age 74 7
Adult female or small male 76 8
Adult male 78 9
Large adult male 80 10
EXPOSURE VALUES
for sinus program “Sinus PA nonrot”
PATIENT kV VALUE mA VALUE
Child up to 6 years of age 72 5
Child 7-12 years of age 74 6
Adult female or small male 76 7
Adult male 78 8
Large adult male 80 9
Bite1.eps
Lip1.eps
Chin support
Adapter
