Planmeca ProOne Installation Manual

Planmeca ProOne 7
Installation Manual
PRE-INSTALLATION INFORMATION
2.6 Dimensions for wall bracket and extension plate (optional)
Wall bracket
Extension plate for wall bracket (optional
)
A
(B)
C
D
E
50 mm (2 in.)
180 mm
(7.1 in.)
150 mm
(5.9 in.)
wallbracket_dim.eps
A
(B)
C
D
E
240 mm
(9.45 in.)
50 mm (2 in.)
25 mm (1 in.)
406.4 mm
(16 in.)
10 mm
(0.4 in.)
