DC emitter, 7 mA, Tube length 20 cm
Without X-ray field
limitation
X-ray field limitation
2x3
X-ray field limitation
3x4
60 kV
mGycm
2
60 kV
mGycm
2
60 kV
mGycm
2
Incisors 0.07 s 12.8 0.07 s 2.7 0.07 s 5.4
Premolars 0.09 s 16.4 0.09 s 3.4 0.09 s 6.9
Molars 0.13 s 23.8 0.13 s 5.0 0.13 s 10.1
Bite wing 0.15 s 27.4 0.13 s 5.0 0.13 s 10.1
DC emitter, 6 mA, Tube length 30 cm
Without X-ray field
limitation
X-ray field limitation
2x3
X-ray field limitation
3x4
60 kV
mGycm
2
60 kV
mGycm
2
60 kV
mGycm
2
Incisors 0.10 s 9.1 0.10 s 1.9 0.10 s 3.8
Premolars 0.13 s 11.8 0.13 s 2.5 0.13 s 5.0
Molars 0.16 s 14.8 0.16 s 3.1 0.16 s 6.2
Bite wing 0.16 s 14.8 0.16 s 3.1 0.16 s 6.2
Check and adjust the specific X-ray unit in accordance with the standard
values.
3.3.5 Acceptance tests
The required tests (e.g. acceptance tests) must be carried out in accordance
with local rules and regulations.
• Find out which tests are required
• Carry out testing in accordance with local rules and regulations
Acceptance test
NOTE
The Intra / Extra Digital test body is required for acceptance tests with the
image plate and sensor as receivers, and possibly also the corresponding
test body holder.
Before the unit is started up and used for the first time, the acceptance test
of the X-ray system must be carried out in accordance with national
regulations.
The constancy tests, which must be carried out at regular intervals by the
surgery personnel, are based on the results of the acceptance test.
For more information, see the Planmeca intraoral imaging system constancy
tests manual (publication number 10009324).
Electrical safety checks
• Carry out the electrical safety check according to the national law (e. g.
in accordance with IEC 62353)
• Document the results
• Instruct and hand over the device and document
3 Assembly
User's manual Planmeca ProScanner 2.0 31
