Environmental Protection
Immunity Guidance
The QuickSee is manufactured to work in the electromagnetic environment as specified in the below
table. The user / operator should make sure it is used within these environmental conditions.
Immunity
Test
Test Level
EN 60601-1-2
Conformity
Level
Electromagnetic
Environment Guide
Electrostatic
Discharge (ESD)
IEC 61000-4-2:2008
± 8 kV contact
± 2 kV, ± 4 kV, ± 8 kV,
± 15 kV, Air
This unit is sensitive
to ESD and may
require restart
The floor should be
wood, concrete, or
ceramic tile. If the
floor is covered with
synthetic material,
relative humidity
should be at least
30%.
Electrical Fast
Transient / Burst
IEC 601000-4-4:
2012
± 2 kV high voltage
power line, 100 KHz
repetition frequency.
± 2 kV high voltage
power line. This unit is
sensitive to EFT and
may require restart
The quality of the
power supply should
be that one of a
typical commercial or
clinical environment.
Surge
IEC 61000-4-5: 2014
Differential mode:
± 1 kV
Differential mode:
± 1 kV
The quality of the
power supply should
be that one of a
typical commercial or
clinical environment.
Magnetic field at
power frequency
IEC 61000-4-8: 2009
30 A/m 50 or 60 Hz 30 A/m 50 or 60 Hz Power frequency
magnetic fields
should have char-
acteristic levels of a
typical commercial or
clinical environment.
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines
IEC 61000-4-11: 2004
95% dip of UT for 0.5
cycle 40% UT (>60%
dip of UT) for 5 cycle
70% UT (>30% dip
of UT) for 25 cycle
95% dip of UT) for 5
seconds
95% dip of UT for 0.5
cycle 40% UT (>60%
dip of UT) for 5 cycle
70% UT (>30% dip
of UT) for 25 cycle
95% dip of UT) for 5
seconds
The quality of the
power supply should
be that one of a
typical commercial or
clinical environment.
If the user requests
a continuous func-
tioning during power
supply interruptions,
it is recommended a
backup power supply
unit (UPS) or battery.
