! Plexxi Switch 3eq Installation Guide (Switch-Control 3.0.0-3.2.x)! 11!
UPS&
For any UPS (Uninterruptible Power Supply) providing power to a Plexxi 3eq switch, Plexxi
recommends the following:
• The UPS must have enough capacity to power the switch plus any other equipment that is connected
to the UPS.
• The UPS must be a double-conversion on-line sine-wave UPS.
Cabling&
Ensure there is ample clearance at the power panel and I/O panel to allow unrestricted cabling. Also
ensure the AC power cords can easily reach from the AC power outlet to the connection on the power
supply panel of the switch.
Unpack!the!Switches!
Unpack all switch components and inspect for shipping damage.
Verify!Equipment!Delivered!
Review the components to ensure that you received what your ordered.
Equipment
Description
Five hot swappable fans
Installed in chassis. A red tab indicates airflow from the
I/O panel to the power panel. A blue tab indicates
airflow from the power panel to the I/O panel.
Two power supplies
Installed in chassis.
Two power cables
For AC connections: 2.5 meter cables which comply
with appropriate country standards.
For DC connections: DC cables.
For redundancy: Connect the power cables to separate
site power circuits.
Cables
Verify that you have all cables ordered for your
installation. For valid cables and part numbers, refer to
the Plexxi Compatibility Matrix.
Rack mount kit
Rack mount for the switch.
Switch!Part!Numbers!and!Options!
Switch 3eq is available with the following power supply and cooling options:
-F = I/O to power panel air flow direction (red, Normal air flow)
-R = Power panel to I/O air flow direction (blue, Reverse air flow)
