7 Adding!a!Switch!to!an!Existing!Fabric!
Follow the guidelines described here to add a Switch 3eq to an existing network. In preparation:
• Identify the numbers or order of the current switches in the fabric, which switch is #1, which is #2,
and so on.
• The new switch being added to the fabric must be the highest-numbered switch.
Adding!Switch!#7!to!a!Six-Switch!Fabric!
You have an existing fabric with six Plexxi 3eq switches. You want to add another switch 3eq to make it
a fabric of seven. To add the switch, you need to shift six existing connections and add three more cables.
To cable a 7
th
switch added to a 6-switch fabric, follow these steps in sequence to move and add cables:
Cable Connection
Steps to accomplish
Switch 6 W1 to Switch 7 E1
1. Unplug Switch 1 E1
2. Plug freed end into Switch 7 E1
Switch 5 W2 to Switch 7 E2
3. Unplug Switch 1 E2
4. Plug freed end into Switch 7 E2
Switch 4 W3 to Switch 7 E3
5. Unplug Switch 1 E3
6. Plug freed end into Switch 7 E3
Switch 6 W2 to Switch 1 E2
7. Unplug Switch 2 E2
8. Plug freed end into Switch 1 E2
Switch 5 W3 to Switch 2 E3
9. Unplug Switch 2 E3
10. Plug freed end into Switch 1 E3
Switch 6 W3 to Switch 2 E3
11. Unplug Switch 3 E3
12. Plug freed end into Switch 2 E3
Switch 7 W1 to Switch 1 E1
13. Plug Switch 7 W1 to Switch 1 E1
Switch 7 W2 to Switch 2 E2
14. Plug Switch 7 W2 to Switch 2 E2
Switch 7 W3 to Switch 3 E3
15. Plug Switch 7 W3 to Switch 3 E3
