Plexxi Switch 3eq - Ports and LEDs; I;O Panel Port Overview; QSFP28 Port Details and Mapping

32! Plexxi Switch 3eq Installation Guide (Switch-Control 3.0.0-3.2.x)! !
9 Ports!and!LEDs!
I/O!Pane l!Ports!
The following illustration identifies the 3eq I/O panel ports:
These ports (and LEDs) are described in the following sections.
QSFP28 to SFP28 Port table
QSFP28
SFP28
QSFP28
SFP28
QSFP28
SFP28
QSFP28
SFP28
1
1-4
9
33-36
17
65-68
25
97-100
2
5-8
10
37-40
18
69-72
26
101-104
3
9-12
11
41-44
19
73-76
27
105-108
4
13-16
12
45-48
20
77-80
28
109-112
5
17-20
13
49-52
21
81-84
29
113-116
6
21-24
14
53-56
22
85-88
30
117-120
7
25-28
15
57-60
23
89-92
31
121-124
8
29-32
16
61-64
24
93-96
32
125-128
!
