SQF-3-33
Replacement
Adjustment
29 November 2006
MECHANICS
Replacement
1. Insert lower clamp [ I ], roller assembly, and springs in the machine.
2. Mount pins [H] centerd in the lower clamp.
3. Apply grease on each end of the lower clamp, by the pins.
4. Insert upper clamp [J].
5. Apply grease on clamp, by brass guides.
NOTE: Make sure no grease gets in contact with the roll.
6. Grease the upper clamp on the infeed side by the roll assembly’s home
position / turning points.
7. Mount the linkage shafts [B], to the upper clamp, and the E-clips on both front
and rear side (
x 2).
NOTE:Makesureatendcorrespondstoatonlinkage.
8. Turn linkage to press down the lower clamp [ I ].
9. Push lower clamp in position.
10. Mount brass guides without tightening the screws (
x 6).
NOTE: Grease the brass guides.
11. Press the brass guides together and tighten the screws. There should be no
play between guides and clamps (
x 6).
CAUTION: The clamps must be centerd in the cut-outs.
12. Turn linkage afterwards to make sure that clamps moves without binding.
13.Cleanclampsonoutfeedsideandpressareawithalcoholuid.
14. Mount lower paper guide (
x4).
15. Mount upper paper guide (
x4).
16. Check Set Stop Gate adjustment (
3.5.2).
17. Reverse the removal procedure.
[ I ]
[ J]
[H]
