3 Versions
Order no.
9407-9 - 1
Basic unit
standard
6
with integrated supply voltage
7
KS98+ with CANopen I/O
*1)
8
90...250 V AC with 4 relays
3
Power supply and 90...250 V AC with 2 relays + 2 current outputs
5
process outputs 24 V UC with 4 relays
7
24 V UC with 2 relays + 2 current outputs
9
Option B
no option B
0
TTL interface + di3...7 / do1...4
1
RS 422 + di3...7 / do1...4 + real-time clock
2
PROFIBUS-DP + di3...7 / do1...4
3
INTERBUS + di3...7 / do1...4
4
Option C
no option C
0
INP3 / INP 4 / OUT 3 / di8...12 / do5 / do6
1
INP3
*2)
/ INP 4 / OUT 3 / di8...12 / do5 / do6
2
modular option c basic card (not with KS98+)
*1)
3
modular option c basic card with modules
*1)
4
Engineering
single-channel controller (basic unit)
0
cascade controller
1
flow controller
2
program controller
3
heat-energy counter
4
flow calculator
5
Setting
standard setting
0
setting to specification
9
*1)
The combination KS98+ (CANopen I/O) and modular option c is not possible! Either KS98+ or modular option c!
*2)
INP3: With type = 0...20 mA the input is scaled to -50...1300 mV. If output INP3 shall be used with this scaling,
x0 must be set to -50 and x100 to 1300.
3.1 I/O-modules - for units with modular option c basic card
Order no.
9 407-998-0 1
Plug position
Separate order
0
Fitted on KS98 slot 1
}
galvanically
connected
1
Fitted on KS98 slot 2
2
Fitted on KS98 slot 3
}
galvanically
connected
3
Fitted on KS98 slot 4
4
Module type
Analog inputs
Pt100 / 1000, Ni 100 /1000, resistance, pot
20
Thermocouple, mV, 0/4...20mA
21
-50...1500mV, 0...10V
22
Module type-
Analog outputs
0/2...10V, 0..._10V
30
0/4...20mA, 0..._20mA
31
Module type
Dig.inputs/outputs
Digital I/O (universal)
40
Frequency/counter input
41
9499 040 50611 Versions
11 I/O-modules - for units with modular option c basic card
