29.4 U_INP (analog input card -50...1500mV, 0...10V)
Analog input, plugs into modular options card
For configuration and parameter setting of the analog input U_INP.
Input calculation is fixed to once per time slot.
Digital outputs:
slotid
0 = correct module fitted
1 = wrong module fitted
fail_a
0 = no measurement error at channel a detected
1 = measurement error at channel a detected; e.g. sensor break
fail_b
0 = no measurement error at channel b detected
1 = measurement error at channel b detected; e.g. sensor break
Analog outputs:
Inp_a r measured value channel a
Inp_b r measured value channel b
Modular I/O - extension-modules U_INP (analog input card -50...1500mV, 0...10V)
U_INP (analog input card -50...1500mV, 0...10V) 232
Fail_a
XaFail
X0_a
X100_a
Tfm_a
Xakorr
x1a in
x1a Out
x2a in
x2a out
fail_a
Inp_a
Typ_a
Fail_b
XbFail
X0_b
X100_b
Tfm_b
Xbkorr
x1b in
x1b Out
x2b in
x2b out
fail_b
Inp_b
slotid
Typ_b
a
b
