11.5 ARCSIN (arcus sinus function)
yx
1
arcsin 1)= (
valid for x x_ :
1111-£ £+
The function provides the arcus sinus of the input value, i.e. x1 is the angle the arcus sinus of which is calculated. Pa-
rameter Select is used to adjust, if the angle is provided in degree of angle [°] or in radian.
The calculation is output as degree of angle [-90° ... 90°] or as radian [-
ó
/
2
...
ó
/
2
]. With arguments out of the function
validity range, output y1 is limited to -1,5 w 10
37
(x1<-1) or 1,5 w 10
37
(x1>1 ).
Example degree of angle:
y1= arcsin(x1) x1 = 0,5° = y1 =30
Example radian:
y1= arcsin(x1) x1 = 1rad = y1 = 1,571
Parameter Description Controller display
Select
Unit: degree of angle (default) Ang.deg
Unit: radian Radian
9499 040 50611 Trigonometric functions
43 ARCSIN (arcus sinus function)
