15.3 TRST ( hold amplifier )
With control input hold set to 1, instantaneous input value x1 is stored and output at y1. With control input hold set to
0, output y1 follows input value x1.
The function has a ‘memory’. This means: after power-on, it continues operating with the y1 value which existed at
power-off, provided that the RAM data are still unchanged.
No parameters!
Inputs/outputs
Digital input
hold
Storage signal for the
x1
value
Analog input
x1
Process value which can be output stored.
Analog output
y1
Function output
9499 040 50611 Selecting and storage
87 TRST ( hold amplifier )
