31.3 Standard engineerings
A detailed description of the standard engineerings is available on request.
Single controller (96xxx001.edg / C9800014.edg)
Versions with standard setting
Basic versions
9407-963-00001 (switching)
-
Signallers, 2-pnt., 3-pnt., 3-pnt. stepping
-
Process value preprocessing (filter and characterizer)
-
2 alarms (selectable: x, xw,weff,y)
-
Trend display for x, xw and weff
-
Bargraph display of x and weff
-
Programmer with 4 recipes each with 20 segments
9407-965-00001 (continuous) as switching version, but:
-
Continuous controllers incl. split range, switching controllers with logic output
-
Analog output for x, xw,weff or y2
Versions with option B function as basic version, plus:
-
Operation disabling via control inputs
-
Output of the programmer output signals
-
Weekly timer for programmer start/stop (option B with clock)
Versions with option C function as basic version, plus:
- 3-element controller
- Override control +, or hard manual
- Galvanically isolated ratio control (x1 ® x2)
- Output of the programmer set-point
- Two additional control outputs for the programmer
Cascade controller (96xxx101.edg / C9800009edg)
Master controller
- Process value input INP5
- Process value preprocessing (filter and characterizer)
- Trends for control deviation and process value
Slave controller
-
As master controller, but process value input INP1
-
Adjustable controller types dependent of switching/continuous version as basic versions
-
Position feedback via INP6
Flow controller (96xxx201.edg / C9800007.edg)
· Temperature and pressure-corrected flow measurement for mass flow (with or without square root extraction )
-
Cycle 100 ms
-
with or without control function
-
trend display for flow and control deviation
-
Totalization with creep flow cut-off
-
Flow display up to 99.999.999
-
Total reset via front panel after entry of a code number
-
Counter pulse output (ones, thousands)
-
Adjustable controller types dependent of switching/continuous version as basic versions
Programmer with 10 recipes (96xxx301.edg / C9800008.edg)
-
10 recipes with 20 segments
-
2 analog output
-
6 control outputs
-
one controller per analog output
-
operation via the analog programmer front panel
-
operation disable via control input
9499 040 50611 Examples
241 Standard engineerings
