Point Mobile PM450 User Manual
5
of 1
of 1 rating
72 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
38
BLUE + F11
F
15
BLUE + F12
F
16
BLUE + 1
Volume Up
BLUE + 4
Volume Down
BLUE + 3
Backlight Up
BLUE + 6
Backlight Down
BLUE + 5
Page Up
BLUE + 0
Page Down
BLUE + 1
Home
BLUE + 9
End
BLUE + ENT
OK
BLUE + TAB
ESC
BLUE + SP
Windows Manu
BLUE + BKSP
Align the screen(Press E
SC to exit)
Key Combination
of Alpha-Numeric
keypad
Function
BLUE + F1
F5
BLUE + F2
F6
BLUE + F3
F7
BLUE + F4
F8
BLUE + 1
F9
BLUE + 2
F
10
BLUE + 3
F
11
BLUE + 4
F
12
BLUE + 5
F
13
BLUE + 6
F
14
BLUE + 7
F
15
BLUE + 8
F
16
BLUE + 9
F
17
BLUE + .
F
18
BLUE + 0
F
19
BLUE + ,
F
20
BLUE +
ENT
OK
BLUE +
TAB
ESC
38
40
Table of Contents
Default Chapter
2
Table of Contents
2
1 Introduction
5
Trademarks
5
About the PM450 Handy Terminal
5
Accessories
5
2 Safety Regulations Hw
6
General Safety Rules
6
Hand Strap
6
Laser Safety
7
Power Supply
7
Laser Safety Statement
8
CB Scheme
9
FCC Part 15 Regulation
9
FCC/EU RF Exposure
9
LED Safety
9
Canadian Compliance
10
Radio Compliance
11
WEEE Compliance
12
Wwan
12
3 Getting Started
12
Install the Battery
12
Charge the Batteries
14
LED Indicators
15
Guidelines for Battery Pack Use and Disposal
15
Turn Your Device on
18
Desktop
18
Indicator Icons
18
Using the Stylus
19
Selecting Program
19
Pop-Up Menus
20
Using Windows Explorer
20
4 Get to Know Your Device
20
Feature of Your Device
20
PM450 Handy Terminal
20
Front Panel Layout
21
Led Indicator
21
Display Backlight
22
Keypad Backlight
23
Using Screen Protectors
23
Installing Your Screen Protector
23
Back Panel Layout
26
Left Side Panel Layout
27
Installing Memory Cards
28
Right Side Panel Layout
28
Top Panel Layout
29
Bottom Panel Layout
29
Peripherals and Accessories
30
Li-Ion Battery Packs
31
Battery Power
31
Main Battery Pack
31
Managing Main Battery Power
32
Resetting the Terminal
33
Suspend Mode
34
Memory Allocation
34
Care and Cleaning of the Products
34
PM450 Technical Specifications
35
5 Using the Keypad
36
Numeric Keypad Layout
36
Navigation Keys
36
Basic Keys
37
Alpha/Numeric Modes of Numeric Keypad
37
Normal/Ctrl Modes of Numeric Keypad
38
White Indicators on the Numeric
38
BLUE Key Combinations
38
Program Buttons
40
6 Using the Image Engine
41
Overview
41
Available Image Engines
42
Depth of Field
42
Supported Bar Code Symbologies
43
Activating the Engine
44
Using Demos
44
Decoding
44
To Decode a Bar Code
44
Sample Bar Codes
45
Omni-Directional Scanning Positions
45
Capturing Images (IT5300SR Engine Only)
46
7 Using the Laser Engine
46
Overview
46
Available Laser Engines
46
Depth of Field
46
Supported Bar Code Symbologies
46
Activating the Engine
48
Using Demos
48
Decoding a Bar Code
48
Sample Bar Code
48
Scanning Positions
49
8 Using Scanwedge
49
Overview
49
Enabling Scanwedge
49
9 Using Control Panel
50
System Properties
50
Version
50
Device ID
51
Copyrights
51
Power Properties
51
Battery Tab
51
Advanced Tab
52
CPU Power Tab
52
Alerts Tab
52
Wakeup Source Tab
52
Battery Info Tab
52
Program Button Properties
52
Program Buttons Tab
52
Key Define Tab
53
Up/Down Control Tab
53
Backlight Properties
53
Program Buttons Tab
54
Battery Power Tab
54
Scanner Settings
54
Scanner Settings
55
Scanner Settings Applet
56
10 Communication
58
Communication Options
58
Installing Additional Software
58
Connecting the USB Activesync Cable
59
Activesync Communication
59
Communication Type
59
Hardware Requirements for Setup
60
Software Requirements for Communication
60
Setting up the Host Workstation
60
Communicating with the Handy Terminal
60
Synchronizing with the Host Workstation
61
Exploring the Terminal from the Workstation
61
Adding Programs Via Activesync
62
Wireless Radios
62
Connecting the Terminal to a Wireless Network
62
WLAN (802.11B/G/N Radio)
63
Adding Programs from the Internet
63
11 Bluetooth Handler
64
Enabling the Bluetooth Radio
64
Connecting to Other Devices
65
Pairing Bluetooth Devices
65
Setting up a Bluetooth Printer
65
12 Single Slot Docking Cradle/Single Slot Ethernet Cradle Device
65
Overview
65
Battery Charging
65
Power Supply
65
Front Panel
66
Back Panel
66
Powering the Single Slot Docking Cradle or Single Slot Ethernet Cradle Device
67
Charging Thebattery
67
Technical Specifications
68
Overview
69
Power Supply
69
4 Slot Battery Charger
70
Front Panel
70
Back Panel
70
Charging Thebattery
71
Technical Specifications
72
