8.11
FRONT SUSPENSION & STEERING
8
SHOCK INFORMATION
IFS Shock Fastener Torques
IFS SHOCK SPECIFICATIONS
*=Serviceable shock
b=IFP depth measured form the bottom of the shock body
t=IFP depth measured form the top of the shock body.
r=IFP depth measured form the top of the remote reservoir.
UNIT IFS UPPER IFS LOWER
ALL 29 ft-lb (39 N-m) 29 ft-lb (39 N-m)
IFS Shocks
SHOCK PN BRAND
EXTENDED
L
ENGTH
(
IN)
COLLAPSED
L
ENGTH (IN)
STROKE
(
IN)
SHOCK
R
OD
(
IN)
IFP DEPTH
(
IN)
SHAFT PN PSI
7041535 Arvin 13.3 10.64 4.47 .49 N/A N/A N/A
7042258* Arvin 18.00 11.8 6.2 .49 6.92 t 1700228 200
7043054 Arvin 17.97 11.83 6.14 .49 N/A N/A N/A
7043141* Fox 18.00 11.80 6.20 .50 1.420 b 1500713 200
7043095* Walker 18.00 11.738 6.27 .625 2.250 1800102 200
7043049 Arvin 17.02 12.77 5.75 .49 N/A N/A N/A
7043090* Arvin 17.00 11.20 5.80 .49 6.54 t 1700231 200
7041932 Arvin 16.28 12.89 5.15 .49 N/A N/A N/a
7041918 Arvin 16.35 11.09 5.26 .49 N/A N/A N/A
7042197 Arvin 17.28 13.78 5.26 .49 N/A N/A N/A
7043082* Arvin 16.25 12.76 5.25 .49 6.27 t 1700025 280
7043206* Walker 18.00 10.13 6.26 .625 2.25r 1800303 200
