11.13
BATTERY & ELECTRICAL SYSTEMS
11
Starter Motor Assembly (Typical)
STARTER SOLENOID
STARTER MOTOR
MOTOR BRACKET
MOTOR BRACKET
GROUND CABLE
14 - 16 Ft.Lbs. (19 - 21 Nm)
19 - 26 Ft.Lbs. (25 - 35 Nm)
9 Ft.Lbs. (12 Nm)
COMMUTATOR CAP
ARMATURE
DRIVE CAP
SCREW
RETURN SPRING ASM
PINION
