1.31
MODEL SPECIFICATIONS
1
Front Suspension
Suspension type IQ
IFS shocks Arvin/7043054
IFS spring rate
(lb/in - kg/mm)
122-2.1
Spring installed length (in/cm) 9.95/25.3
Front vertical travel (in/cm) 10/25.4
Ski center distance (in/cm)
41.16
"
104.5
Camber (in/mm)
2.25
" ±.31"
5.7 ±.79
Toe (in/mm)
0-.12
"
0-3
* notes that shock is serviceable
Rear Suspension
Suspension type M-10 136
Front track shock (FTS) Arvin /7043207
FTS spring rate
lbs-in/kg-mm
220/3.9
FTS spring installed length (in/cm) 8.5/21.6
Rear track shock Fox /7043216*
Rear travel (in/cm) 14/35.6
* notes that shock is serviceable
Dimensions
Width (in/cm) 48/121.9
Length (in/cm) 129/327.7
Height (in/cm) 53/134.6
Est dry weight lb/kg 574/260.6
Electrical
Ignition timing
18° @ 1700 RPM (±200
RPM) & 120° F (±10° F)
49 ° C (±12° C) water
temp
Spark plug gap (in/mm) .027/.70
Spark plug Champion RN57YCC
Voltage regulator/output 280watt
Base ECU 4011518
