Polaris 2007 Two Stroke User Manual

1.33
MODEL SPECIFICATIONS
1
Track
Width (in/cm) 15/38
Length (in/cm) 121/307
Lug height (in/cm) 1.25/3.2
Manufacturer Camoplast
Track tension sag (in/cm) with 10 lbs/
4.54kg placed 16 in/40.6cm ahead of
rear idler shaft
.875-1.125/2.2-.9
Front Suspension
Suspension type IQ 121 Dragon
IFS shocks Walker/7043206*
IFS spring rate lbs-in/kg-mm 100/1.79
Spring installed length (in/cm) 11.17/28.4
Front vertical travel (in/cm) 10.55/26.8
Ski center distance (in/cm) 42.5/108
Camber (in/cm) 2.25±.31/5.7±.79
Toe (in/mm) 0-.12/0-3.0
* notes that shock is serviceable
Rear Suspension
Suspension type IQ 121
Front track shock (FTS) Walker/7043204*
FTS spring rate (lbs/in-kg/mm) 130-270/2.3-4.8
FTS spring installed length (in/cm) 7.97/20.2
Rear track shock Walker/7043205*
Rear vertical travel (in/cm) 13.9/35.3
* notes that shock is serviceable
Torsion Spring
Torsion spring PNs
(LH/RH)
7043070/7043071
Torsion spring diameter (in/mm)
.347
Torsion spring tail angle
80°
Dimensions
Width (in/cm) 47.25/120
Length (in/cm) 115/292
Height (in/cm) 47/119
Est dry weight lb/kg 476/216.4
Electrical
Stator output 400w
Ignition timing BTDC @ RPM
18° @ 1700 RPM (±200
RPM) & 120° F (
±10° F)
49 ° C (
±12° C) water
temp
Spark plug gap (in/mm) .027/.70
Spark plug Champion RN57YCC
Base ECU 4011518
Features
Electric Fuel Gauge N/A
Electric Start Accessory
Low Oil Light Standard
Parking Brake Standard
Speedometer Standard
Tachometer Standard
