6.5
BRAKES
6
9923983 - 2012-2013 RZR 170 Service Manual
© Copyright 2012 Polaris Sales Inc.
BRAKE SYSTEM - MECHANICAL COMPONENTS
Brake System - Mechanical Components
Parking Brake Switch
Brake Light Switch Spring
Parking Brake Cable
Pedal Return Spring
12 ft-lb
(16 Nm)
