1.2
GENERAL INFORMATION
9923983 - 2012-2013 RZR 170 Service Manual
© Copyright 2012 Polaris Sales Inc.
MODEL NUMBER DESIGNATIONS
Model Number Designation
Example: R12VA17AA
VEHICLE IDENTIFICATION NUMBER
VIN Number Designation
Example: RF3VA17A6BT012516
Engine Designation Number
S35C-Single Cylinder, Air/Oil Cooled, OHV 4 Stroke, Electric Start
Engine Serial Number Location
Whenever corresponding about an engine, be sure to refer to the engine
model number and serial number. This information can be found on the
sticker applied to the clutch-side engine case.
GROUP
MODEL
YEAR
CHASSIS DRIVELINE ENGINE CATEGORY OPTION
1st digit 2/3rd digit 4th digit* 5th digit* 6th digit* 7th digit* 8th digit 9th digit**
R= RANGER
12
13
V = RZR A = 2x4 Chain
Displacement in cc
(i.e. 17 = 170cc)
A = ORV A
* = digits that would transfer to 17 digit VIN and are used in digits 4-8 respectively
** = 9th digit will be used on color/featured versions of models (not including the base)
First 3 digits and 9th digit are used in model number only. They are not used with the 17 digit VIN.
World Mfg. ID
Vehicle Descriptors Vehicle Identifiers
Chassis Driveline Engine Size Engine Modifier Category Check Digit Model Year * Mfg. Location
Individual Serial No.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
R F 3 V A 1 7 A 6 B T 0 1 2 5 1 6
* Model Year: A = 2010; B = 2011; C = 2012; D = 2013
ENGINE SERIAL NUMBER
