4.45
COMPONENT CONDITION SPN FMI P-CODE
EPS Power Save Condition
EPS: Key On, Engine Off, 5 Minute
Power Save/Timeout
520231 31 C1071
Idle Air Control Valve (IAC)
M17; IAC Stepper Pin 3
Driver Circuit Short to B+
520268
3 P1519
Driver Circuit Grounded 4 P1518
Driver Circuit Open / Grounded
5
P1515
Mechanical System Not
Responding
7 P1559
Out Of Calibration 13 P1302
Idle Air Control Valve (IAC)
M17; IAC Stepper Pin 4
Driver Circuit Short to B+
520269
3 P1529
Driver Circuit Grounded 4 P1528
Driver Circuit Open / Grounded
5 P1525
Mechanical System Not
Responding
7 P1579
Out Of Calibration 13 P1303
Idle Air Control Valve (IAC)
M17; IAC Stepper Pin 6
Driver Circuit Short to B+
520270
3 P1539
Driver Circuit Grounded 4 P1538
Driver Circuit Open / Grounded
5 P1535
Mechanical System Not
Responding
7 P1589
Out Of Calibration 13 P1304
Idle Air Control Valve (IAC)
M17; IAC Stepper Pin 1
Driver Circuit Short to B+
520271
3 P1509
Driver Circuit Grounded 4 P1508
Driver Circuit Open / Grounded
5
P1505
Mechanical System Not
Responding
7 P1549
Out Of Calibration 13 P1301
Accelerator Position / Brake
Position Interaction
Condition Exists 520275 31 P150A
Throttle Position Sensor
(1 or 2 Indeterminable)
Position Sensor Correlation Fault
520276
2 P150C
Neither Position Sensor Passed
Test
12 P150B
Throttle Body Control - Power
Stage
Not Plausible
520277
2 P151A
Voltage Above Normal
3 P150D
Voltage Below Normal
4 P150E
Signal Error
8 P151B
Deactivated power stages due to
5V sensor supply error
31 P153F
Throttle Body Control - Return
Spring Check Failed
Condition Exists 520278 31 P151C
Throttle Body Control -
Adaptation Aborted
Condition Exists 520279 31 P151D
Throttle Body Control - Limp
Home Position Check Failed
Condition Exists 520280 31 P151E
Throttle Body Control -
Mechanical Stop Adaptation
Failure
Condition Exists 520281 31 P152A
Throttle Body Control -
Repeated Adaptation Failed
Condition Exists 520282 31 P152B
