5.8
9926816 R07 - 2014-2016 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
PVT SYSTEM SERVICE
PVT COVERS AND DUCT COMPONENTS
q
CLUTCH DUCT INTAKE ASSEMBLY
s
BRACKET, COVER GUARD
w
CLAMP, WORM
d
AIR INLET DUCT
e
DECAL, CAUTION
f
SCREW
r
BOLT and WASHER
g
SCREW
t
COVER ASSEMBLY, OUTER
h
NUT, NYLOK
y
O-RING
j
BRACKET, BELT SCREEN
u
DRAIN PLUG, COVER
k
HOSE, AIR OUTLET
i
SEAL, COVER
l
INTAKE BOOT
o
SCREW
1(
SEAL, COVER
a
COVER ASSEMBLY
PVT SYSTEM
