9926816 R07 - 2014-2016 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
9.3
GENERAL INFORMATION
TORQUE SPECIFICATIONS
ITEM
TORQUE
Caliper Mounting Bolts (Front) 30 ft-lb (41 Nm)
Caliper Mounting Bolts (Rear) 46 ft-lbs (62 Nm)
Brake Line Flare
15 ft-lb (20 Nm)
Brake Line Banjo Bolts 15 ft-lb (20 Nm)
Brake Switch
15 ft-lb (20 Nm)
Brake Bleeder Screw
48 in-lb (5 Nm)
Brake Disc to Hub Bolts
18 ft-lb (24 Nm)
Master Cylinder Mounting
Bolts
23 ft-lbs (31 Nm)
Brake Pedal Mounting
Bracket to Frame
18 ft-lb (24 Nm)
Park Brake Disc Mounting
Bolt
14 ft-lb (20 Nm)
Park Brake Lever Mount Bolts
16 ft-lb (22 Nm)
Park Brake Caliper Assembly
Bolts
37 ft-lb (50 Nm)
Wheel Hub Castle Nuts
110 ft-lbs (149 Nm)
Wheel Lug Nuts
Aluminum: 120 ft-lbs
(163 Nm)
Steel: 60 ft-lb (81 Nm)
SPECIAL TOOLS
PART NUMBER TOOL DESCRIPTION
2870975
Mity Vac™ Pressure Test Tool
Bosch Automotive Service Solutions:
1-800-345-2233 or http://polaris.service-solutions.com/
BRAKE SYSTEM
