9926816 R07 - 2014-2016 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
2.21
THROTTLE PEDAL INSPECTION
This vehicle is equipped with Pedal Position Sensor
q
used to detect when the throttle pedal
w
is pushed or
released.
The throttle pedal should move freely and always return
back to its idle position when released.
Check throttle pedal periodically.
ENGINE INTAKE PRE-FILTER SERVICE
It is recommended that the engine intake pre-filter be
inspected daily. The filter should be inspected using the
following procedure:
1. The engine intake pre-filter is located just above the
right rear wheel fender.
2. Loosen the knob on top of the assembly and lift up to
disengage the tab from the cargo box.
3. Inspect the pre-filter. If necessary, clean with soapy
water and dry with low pressure compressed air.
MAINTENANCE
