FAN RELAY provides power to the following system:
• Fan Motor
COLOR FUNCTION
Red
Fan circuit breaker protected 12
Vdc constant battery power.
Orange / White
ECU ground input to enable
relay.
Red / Dark Blue
12 Vdc switched power from EFI
relay.
Orange / Black
Provides 12 Vdc power for fan
operation.
FUEL PUMP RELAY provides power to the following
system:
• Fuel Pump
COLOR FUNCTION
Red / Green
10-Amp fuse protected 12 Vdc
battery voltage.
Dark Green /
Yellow
ECU ground input to enable
relay.
Red / Dark Blue
12 Vdc switched power from EFI
relay.
Red / Blue
Provides 12 Vdc power for fuel
pump operation.
EPS RELAY (OPT) provides power to the following
system:
• Electronic Power Steering Unit
COLOR FUNCTION
Red
EPS fuse protected 12 Vdc
constant battery voltage.
Brown
Relay coil ground.
Orange
12 Vdc power input from key
switch to enable relay.
Orange
Provides 12 Vdc power for EPS
operation.
REAR DIFF SOLENOID RELAY (INT’L) provides power
to the following system:
• Rear Differential Solenoid
COLOR FUNCTION
Red / Dark Green
10-Amp fuse protected 12 Vdc
battery voltage.
Dark Green /
White
ECU input to enable relay.
Brown
Relay coil ground.
Red
Relay switched power to operate
the Rear Diff Solenoid.
Blue
Ground to energize the Rear Diff
Solenoid.
HEADLIGHT RELAY (INT’L) provides power to the
following system:
• Headlights
COLOR FUNCTION
Red / Yellow
20-Amp fuse protected 12 Vdc
battery voltage.
White / Red
Key switch input to enable relay.
Brown
Relay coil ground.
Yellow / Dark
Green
Relay switched power to operate
the Headlights.
FLASH TO PASS RELAY (INT’L) provides power to the
following system:
• Momentary High Beam Headlight Operation
COLOR FUNCTION
Dark Green
12 Vdc switched power from
headlight relay used to operate
low beam headlights during
“normally closed” relay
operation.
Brown
Relay coil ground.
Yellow
High beam input to “open” relay
and disable low beam headlights
in order to operate high beam
headlights momentarily.
Dark Green
“Normally closed” relay output to
operate low-beam headlights.
ELECTRICAL
