9926816 R07 - 2014-2016 RZR XP 1000 / XP4 1000 Service Manual
© Copyright Polaris Industries Inc.
2.37
FOX internal bypass shocks are position sensitive and become progressively stiffer as the suspension compresses. To
maintain the intended ride comfort, it is important that ride height is maintained to the factory setting.
Adding extra weight to the vehicle will decrease ride height and cause the shock to operate in the stiffer bypass zones.
To correctly compensate for added cargo or accessory weight, spring preload should be added to keep the shock in
the optimal zone and maintain ground clearance.
Refer to the following adjustment table to correctly compensate for weight added to the vehicle.
NOTE
These settings are only guidelines. The spring preload and shock clickers can be adjusted further to match personal
riding style and location of the weight on the vehicle.
FOX Internal Bypass Shock Adjustments
RIDERS
CARGO +
ACCESSORIES
SPRING
ADJUSTMENT
FRONT SHOCK REAR SHOCK
Driver Only
0
Remove 0.2″ (5 mm)
preload, front and
rear
16 clicks out 16 clicks out
Driver +1 0
Factory default
12 clicks out 12 clicks out
Driver +1
100 lbs (45 kg)
Add 0.2″ (5 mm)
preload, front and
rear
10 clicks out 10 clicks out
Driver +1
200 lbs (91 kg)
Add 0.4″ (10 mm)
preload, front and
rear
8 clicks out 8 clicks out
Driver +1
300 lbs (136 kg)
Add 0.6″ (15 mm)
preload, front and
rear
6 clicks out 6 clicks out
* shaded cells are factory default settings
MAINTENANCE
